FBx Series DNP3 Driver File Read Sequence Info

Used by: FBx Series DNP3 driver tag

The FBx Series DNP3 Driver File Read Sequence Info widget will create a button that will open a table displaying the driver reads.

File Type

This is the file type that was being looked for during the read. (Ex. history, alarm & events)

Instance

The instance corresponds to a specifications table provided by Emerson.

Last Sequence Read

Each available record is ordered by sequence. The last sequence read denotes the most recent record received in sequence.

Newest Sequence Available

If there are new records available they will have a higher sequence number than the last sequence read. By default, the read will include all new records after the last sequence read up to the newest sequence available.

Last Read Record TS

A time stamp from the last read record.

Reset

"Reset Sequence" will reset last sequence read to 0 and the next read will retrieve every sequence up to the newest sequence available.



The properties dialog for the FBx Series DNP3 Driver File Read Sequence Info widget:

Link your FBx Series DNP3 Driver tag, customize the button label or disable selected operator features.

Button Label

Text to display on the button

Disable Options

Disable selected operator-interaction features of this widget.

See: Operator Interaction Controls
